SD 200
Switch disconnector acc. to IEC/EN 60947-3 for panel installation onto DIN rail (35mm)
Mounting depth: 68mm
Mounting width: per pole = 17.5mm = 1 module
Colour: grey, RAL 7035
Colour of switch lever: red RAL 3000
Special features
• Isolating characteristics acc. to IEC/EN 60947-3
• Clear contact position indication in red/green (“Real CPI”)
• Highest performance at an increased voltage level: 25 kA conditional short-circuit current
at U
e
= 253/440 V AC acc. to IEC/EN 60947-3
• Protection degree IP20 = finger safe
• 35 mm² cylinder lift terminal with 2 terminal openings for two wires or one wire and one
busbar for cross wiring
• Bottom fixed auxiliary contact as accessory for a space saving installation or upgrade of
existing assemblies without additional mounting width
• Consistent design to other System pro M DIN rail products
• Cross wiring with MCBs or RCDs using busbars PS
• Durable device identification due to laser labeling
• Captive screws
• Compatibility with all MCB accessories
• Approved acc. to IEC/EN 60947-3 for international use
