HYUNDAI UAB/UCB Type Molded Case Circuit Breakers
| Compact size
• High breaking capacity in 60mm depth, up to 250AF
• Application of current-limiting technology
• UAB type
- up to 25kA at AC380/415V in W75 x H130 x D60mm
• UCB type
- up to 50kA at AC380/415V in W90/105 x H165 x D60mm
| Reliable quality
• Type-tested by KEMA Netherlands
| Wide and powerful range
• 50, 125, 250, 400, 630, 800, 1000, 1250, 1600AF
• Fixed or adjustable thermal trip mechanism up to 800AF
• Double protected electronic trip mechanism for 1600AF
| Various accessories
• Motor operator and operating handles for smooth
operation
• Terminal cover and terminal busbar for safety
• DIN rail adapter and mounting base for easy installation
• Switches and trip devices for control by signals
