DIN Track-mounted, 22.5-mm-width Standard Timer Series
• A wide AC/DC power supply range (24 to 240 VAC/DC).*1 • All sub-series include models with 12-VDC power supply.*1 • G-type Models (H3DK-G) now include model with 240 to 440- VAC power supply. • UL*2, CSA*3, and CCC certification and EN 61812-1 compliance. CE Marking. • EMC (EN 61812-1) compliance for application in heavy industrial, residential, commercial, or light industrial environments. • Finger-safe terminal block and captive screws according to EN 50274.
• Multiple time ranges and operating modes let you cover a wide range of applications. • The time-limit DPDT output contacts can be changed to time-limit SPDT and instantaneous SPDT output contacts using a switch. • Sequence checks are easily performed by setting an instantaneous output to 0. • Start signal control for the H3DK-M.
